Submersible Motor Submersible Motor
25-250HP(18.5-185KW) YQS250 SERIES SUBMERSIBLE MOTOR
OEM or customization is acceptable.
Size Range:：
Applications：
AOTE 25-252HP(18.5-185KW) YQS250 Series AC 3 Phase Submersible Motor
Material: Stainless Steel/ Cast Iron/ Customization
SPECIFICATIONS
Type | Power | Rated Voltage (V) | Rated Current (A) | Efficency (%) | |
|---|---|---|---|---|---|
HP | KW | ||||
YQS250-18.5 | 25 | 18.5 | 380 | 41.0 | 82.0 |
YQS250-22 | 30 | 22 | 48.0 | 83.0 | |
YQS250-25 | 35 | 25 | 54.0 | 84.0 | |
YQS250-30 | 40 | 40 | 64.0 | 84.5 | |
YQS250-37 | 50 | 37 | 78.0 | 85.0 | |
YQS250-45 | 60 | 45 | 94.0 | 85.5 | |
YQS250-55 | 75 | 55 | 114.0 | 86.0 | |
YQS250-63 | 87 | 63 | 131.0 | 86.0 | |
YQS250-75 | 102 | 75 | 152.0 | 87.0 | |
YQS250-90 | 122 | 90 | 183.0 | 87.0 | |
YQS250-100 | 136 | 100 | 203.0 | 87.0 | |
YQS250-110 | 145 | 110 | 227.0 | 87.5 | |
YQS250-120 | 163 | 120 | 244.0 | 87.5 | |
YQS250-125 | 165 | 125 | 258.0 | 87.5 | |
YQS250-132 | 175 | 132 | 265.0 | 88.0 | |
YQS250-140 | 190 | 140 | 286.0 | 88.0 | |
YQS250-150 | 204 | 150 | 307.0 | 88.0 | |
YQS250-160 | 218 | 160 | 327.0 | 89.0 | |
YQS250-185 | 252 | 185 | 378.0 | 89.0 | |
